X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923

Product Categories
Mianyang Baoheng New Material Technology Co.,Ltd
Contact Now

X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923

  • 1
  • 2

Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Model Number : X22CrMoV12-1, X22CrNiMoV12-1,W-Nr 1.4923

Certification : SGS,TUV,BV,ISO,MTC

Place of Origin : China

MOQ : Negotiations

Price : Negotiations

Payment Terms : T/T

Supply Ability : 90000KGS/Month

Delivery Time : Ex-stock for delivery: 5-7 days Production lead time: 45-55days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Product Name : X22CrMoV12-1 Stainless Steel Sheets Plates

Grades : X22CrMoV12-1, X22CrNiMoV12-1,W-Nr 1.4923

Processing methods : Shot blasted,Ground,Peeled,etc

Surface : Centreless Ground,Rrough Turned,etc

Profile : Round Bar,Flat Bar,Sheets Plates,etc

Price Term : Ex-work,FOB,CFR,etc.

Contact Now

X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923


Description

X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923 is Heat-treatable high-temperature steel with good thermal resistance up to 580 °C and scaling resistance up to 600 °C.
All of X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923 conform to Military standard, nuclear power. 100% Ultrasonic test SEP 1923/SAE AMS 2154 /EN 10228-3 /GB/T 4162 /ASTM E2375 .

  • Shape:Stainless Steel Sheets Plates
  • Material:Metal,UNS S13800 Stainless Steel Sheets Plates Shot blasted

  • Steel strip via cold rolled: T0.1 - 3mm X W5 - 200mm X L (or in coil form)

  • Length: Fixed length or random length or based on the customer's special requirement.

  • Sheet steel via cold rolled: T0.5 - 6mm X W6 - 1000mm X L1000 - 2000mm

  • Square bar / Flat bar: 3mm to 800mm

  • Heavy/middle plate via hot rolled: T6 - 200mm X W10 - 1500mm X L1000-12000mm


Products Details

X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923

Chemical Composition (weight%): Carbon, C (％): 0.18 ~ 0.24
Silicon, Si (％): ≤ 0.50
Manganese, Mn (％): 0.40 ~ 0.90
Phosphorus, P (％)≤: 0.025
Sulfur, S (％)≤: 0.015
Chromium, Cr (％): 11.0 ~ 12.5
Nickel, Ni (％): 0.30 ~ 0.80
Molybdenum, Mo (％): 0.80 ~ 1.20
Nitrogen, N (%): -
Aluminum, Al (%): -
Niobium, Nb (%): -
Vanadium, V (％): 0.20 ~ 0.35
Mechanical Properties Under
Final Heat Treatment:		 Condition: solution treatment
Tensile strength, σb/MPa: 700 ~ 850
Yield strength, σs≥/MPa: 600
Elongation, δ5≥(％): 14.0
Non-scale temperature in Air: 600℃


X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923


Applications:


X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923 used most often in the reactor engineering, chemical industry as well as in turbine, steam boiler and pipeline construction and for screws and nuts.

X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923
X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923


FAQ

Q: How do you control the quality?


A: We have professional inspectors to analyze the chemical composition of X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923 and test the finished products in strict accordance with the standards stipulated in the contract. In this process, the inner and outer surfaces, the appearance of both ends, set length, bending, outer diameter and Wall thickness will be checked one by one. You can rest assured that all products you receive from us are reliable.


Q: Do you accept customization?


A: Yes. If you have special requirements for products or packaging, we can make them for you.


Q: Can you accept trial orders?


A: Our MOQ is usually 1000KG.If you want to place an order as the start of our cooperation, we can accept smaller quantities at the first time. Of course, after the start, We will have more stable and long-term cooperation.


Q: How do I get samples?


A: Free samples are available for your inspection and testing, FedEx/DHL/UPS accounts can be used for sampling, and the transportation cost is borne by you.


X22CrMoV12-1 Stainless Steel Sheets Plates W-Nr 1.4923
